Hardwired Level 2 EV Charging Station (240V J1772) for Home Installation

Circuit-Ready Wall Interface

This Level 2 charging unit is configured for direct hardwired installation to a 240V AC supply. It supports circuit capacities ranging from 20A to 80A, with output settings up to 50A depending on electrical configuration. The enclosure is constructed for wall mounting with integrated cable management. A J1772 connector is included for compatibility with standard non-proprietary EV charge ports.

Current Flow And Delivery Path

The system converts 240V AC input into controlled current delivery through a single charging port. Output is regulated based on the configured amperage and vehicle acceptance rate. The unit operates on a dedicated circuit and maintains continuous current transfer during connection. A 23 ft cable provides reach between the wall unit and vehicle inlet without repositioning.

Fixed Installation And Cable Handling

Installation requires direct wiring to a compatible electrical panel and is typically performed at a garage wall or exterior mounting surface. The unit mounts using a fixed bracket system for stable placement. The charging cable remains attached to the unit and can be looped or hung when not in use. No plug interface is included due to hardwired configuration.

Product Benefits:

• J1772 Connector Compatibility: Fits electric vehicles equipped with the standard J1772 charging inlet.
• Hardwired Power Input: Connects directly to a 240V circuit without a plug interface.
• Adjustable Current Configuration: Supports circuit ratings from 20A to 80A with output settings up to 50A.
• Extended Cable Reach: Includes a 23 ft charging cable for flexible vehicle positioning.
• Wall-Mounted Form Factor: Installs on garage or exterior walls using a fixed mounting bracket.

Specifications:

• Material: Polymer housing with sealed internal electrical assembly
• Power Source: 240V AC hardwired connection
• Current Rating: Up to 80A circuit capacity

• Configured Output: Up to 50A continuous output
• Connector Type: SAE J1772 vehicle connector (single port)

• Cable Length: 23 ft integrated charging cable

• Number of Ports: 1 charging outlet

• Installation Type: Fixed wall-mounted, indoor or outdoor placement

• Operating Requirement: Dedicated 20A to 80A branch circuit (Supports circuit capacities up to 80A; maximum charging output is 50A)
• Use Area: Residential garage or exterior wall near vehicle parking location
